| Name | Connector |
| Series | MMCX |
| Gender | Jack |
| Orientation | Right Angle |
| Impedance | 50 Ohm |
| Frequency Range(max) | 6 GHz |
| VSWR | ≤1.20/1Ghz |
| Working Voltage | 170 Volts RMS Continuous |
| Insulation Resistance | 500 MΩ Min |
| Center Contact Resistance | 10 mΩ Max |
| Outer Contact Resistance | 5 mΩ Max |
| Thermal Shock | MIL-STD-202, Method 107 |
| Operating Temperature | −40°C to +90°C |
| Corrosion | MIL-STD-202, Method 101 (Test Condition B) - 5% Salt Solution |
| Mechanical Shock | MIL-STD-202, Method 213, Condition B |
| Vibration |
CECC 22000 4.6.3 |
| Moisture Resistance | MIL-STD-202, Method 103, Condition B |
| Durability | 500 Min |
