| Name | Connector |
| Series | SMB |
| Gender | Plug |
| Orientation | Right Angle |
| Impedance | 50 Ohm |
| Finish | Gold |
| Frequency Range | 4 GHz |
| VSWR | |
| Working Voltage | 335 Volts RMS Continuous |
| Insulation Resistance | 1000 MΩ Min |
| Thermal Shock | MIL-STD-202, Method 107 (Test Condition B) except high temp test @ +200°C |
| Operating Temperature | -65°C to +165°C |
| Corrosion | MIL-STD-202, Method 101 (Test Condition B) - 5% Salt Solution |
| Shock | MIL-STD-202, Method 213 (Test Condition I) - No Discontinuity Permitted |
| Vibration |
MIL-STD-202, Method 204 (Test Condition D) |
| Moisture | MIL-STD-202, Method 106 |
| Durability | 500 Min |
